Ever wondered how to do animations in your android app? In this tutorial I will show you how to do basic and custom animations such as Fade in, Fade out, Rotate and multi animations simultaneously. You may use to some of these animations in your apps to enhance your apps user experience. People love using apps with interactivity!!

Language: Java
Software: Android Studio 3.1
Classes: MainActivity.java,  activity_main.xml, fadein.xml, fadeout.xml, rotate.xml, customanim.xml, logo.png



CODE:



MainActivity.java

package com.subzdesigns.animationsandroid;

import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;

/**
 * Created by Subz Designs.
 * Developed by Tansu Canturk
 */

import android.content.Intent;
import android.os.Handler;
import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.view.View;
import android.view.animation.AlphaAnimation;
import android.view.animation.Animation;
import android.view.animation.AnimationUtils;
import android.view.animation.DecelerateInterpolator;
import android.view.animation.LinearInterpolator;
import android.view.animation.RotateAnimation;
import android.view.animation.TranslateAnimation;
import android.widget.Button;
import android.widget.ImageView;
import android.widget.TextView;
import android.widget.Toast;

import java.util.Random;

public class MainActivity extends AppCompatActivity
{

    @Override
    protected void onCreate(Bundle savedInstanceState)
    {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        final ImageView img_animation1 = (ImageView)findViewById(R.id.imgLogo);

        Button fadein = (Button) findViewById(R.id.fadein);
        Button fadeout = (Button) findViewById(R.id.fadeout);
        Button rotate = (Button) findViewById(R.id.rotate);
        Button customanim = (Button) findViewById(R.id.customanim);
        Button randombtn = (Button) findViewById(R.id.randombtn);

        fadein.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View view) {

                img_animation1.startAnimation(AnimationUtils.loadAnimation(getApplicationContext(), R.anim.fadein));

            }
        });

        fadeout.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View view) {

                img_animation1.startAnimation(AnimationUtils.loadAnimation(getApplicationContext(), R.anim.fadeout));

            }
        });

        rotate.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View view) {

                img_animation1.startAnimation(AnimationUtils.loadAnimation(getApplicationContext(), R.anim.rotate));

            }
        });

        customanim.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View view) {

                img_animation1.startAnimation(AnimationUtils.loadAnimation(getApplicationContext(), R.anim.customanim));

            }
        });

        randombtn.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View view) {


                int min = 1;
                int max = 6;

                Random r = new Random();
                int i1 = r.nextInt(max - min + 1) + min;

                if (i1 == 1) {
                    Toast.makeText(getApplicationContext(), "Fade in", Toast.LENGTH_SHORT).show();
                    img_animation1.startAnimation(AnimationUtils.loadAnimation(getApplicationContext(), R.anim.fadein));
                }
                else if (i1 == 2) {
                    Toast.makeText(getApplicationContext(), "Fade out", Toast.LENGTH_SHORT).show();
                    img_animation1.startAnimation(AnimationUtils.loadAnimation(getApplicationContext(), R.anim.fadeout));
                }

                else if (i1 == 3) {
                    Toast.makeText(getApplicationContext(), "Rotate", Toast.LENGTH_SHORT).show();
                    img_animation1.startAnimation(AnimationUtils.loadAnimation(getApplicationContext(), R.anim.rotate));
                }

                else if (i1 == 4) {
                    Toast.makeText(getApplicationContext(), "Rotate", Toast.LENGTH_SHORT).show();
                    img_animation1.startAnimation(AnimationUtils.loadAnimation(getApplicationContext(), R.anim.rotate));
                }

                else if (i1 == 5) {
                    Toast.makeText(getApplicationContext(), "Custom", Toast.LENGTH_SHORT).show();
                    img_animation1.startAnimation(AnimationUtils.loadAnimation(getApplicationContext(), R.anim.customanim));
                }
            }
        });
    }
}



activity_main.xml

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:background="#fff"
    tools:context="com.subzdesigns.animationsandroid.MainActivity">

    <ImageView
        android:id="@+id/imgLogo"
        android:layout_width="wrap_content"
        android:layout_height="350dp"
        android:layout_alignParentStart="true"
        android:layout_alignParentTop="true"
        android:paddingLeft="50dp"
        android:paddingRight="50dp"
        android:src="@drawable/logo" />

    <Button
        android:id="@+id/fadein"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_alignParentStart="true"
        android:layout_below="@+id/imgLogo"
        android:text="Fade in" />

    <Button
        android:id="@+id/fadeout"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_alignParentStart="true"
        android:layout_below="@+id/imgLogo"
        android:layout_marginStart="101dp"
        android:text="Fade out" />

    <Button
        android:id="@+id/rotate"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_alignParentEnd="true"
        android:layout_below="@+id/imgLogo"
        android:layout_marginEnd="94dp"
        android:text="Rotate" />

    <Button
        android:id="@+id/customanim"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_alignParentEnd="true"
        android:layout_below="@+id/imgLogo"
        android:text="Custom" />

    <Button
        android:id="@+id/randombtn"
        android:layout_width="173dp"
        android:layout_height="wrap_content"
        android:layout_alignParentBottom="true"
        android:layout_centerHorizontal="true"
        android:layout_marginBottom="32dp"
        android:text="Random" />

</RelativeLayout>



fadein.xml

<?xml version="1.0" encoding="utf-8"?>
<set xmlns:android="http://schemas.android.com/apk/res/android">
    <alpha
        android:duration="4000"
        android:fromAlpha="0.0"
        android:interpolator="@android:anim/accelerate_interpolator"
        android:toAlpha="1.0" />
</set>



fadeout.xml

<?xml version="1.0" encoding="utf-8"?>
<set xmlns:android="http://schemas.android.com/apk/res/android">
    <alpha
        android:duration="2000"
        android:fromAlpha="1.0"
        android:interpolator="@android:anim/accelerate_interpolator"
        android:toAlpha="0.0" />
</set>



rotate.xml

<?xml version="1.0" encoding="utf-8"?>
<set xmlns:android="http://schemas.android.com/apk/res/android">
    <rotate
        android:duration="1000"
        android:interpolator="@android:anim/cycle_interpolator"
        android:pivotX="50%"
        android:pivotY="50%"
        android:startOffset="800"
        android:repeatCount="1"
        android:repeatMode="restart"
        android:toDegrees="360" />
</set>



customanim.xml

<?xml version="1.0" encoding="utf-8"?>
<set xmlns:android="http://schemas.android.com/apk/res/android"
    android:fillAfter="true"
    android:interpolator="@android:anim/linear_interpolator" >

    <translate
        android:duration="800"
        android:fillAfter="true"
        android:fromXDelta="0%p"
        android:startOffset="300"
        android:toXDelta="50%p" />
    <translate
        android:duration="800"
        android:fillAfter="true"
        android:fromYDelta="0%p"
        android:startOffset="1100"
        android:toYDelta="90%p" />
    <translate
        android:duration="800"
        android:fillAfter="true"
        android:fromXDelta="0%p"
        android:startOffset="1900"
        android:toXDelta="-75%p" />
    <translate
        android:duration="800"
        android:fillAfter="true"
        android:fromYDelta="0%p"
        android:startOffset="2700"
        android:toYDelta="-90%p" />

        <set xmlns:android="http://schemas.android.com/apk/res/android">
            <translate
                android:duration="1000"
                android:fromYDelta="40%"
                android:toYDelta="0" />

            <translate
                android:startOffset="3100"
                android:duration="1000"
                android:fillAfter="true"
                android:fromYDelta="-80%"
                android:toYDelta="0" />

            <set xmlns:android="http://schemas.android.com/apk/res/android">
                <scale
                    xmlns:android="http://schemas.android.com/apk/res/android"
                    android:duration="3000"
                    android:fromXScale="1.0"
                    android:fromYScale="1.0"
                    android:pivotX="50%"
                    android:pivotY="50%"
                    android:toXScale="0.5"
                    android:toYScale="0.5" >
                </scale>

                <rotate
                    android:startOffset="3500"
                    android:duration="3000"
                    android:fromDegrees="0"
                    android:pivotX="50%"
                    android:pivotY="50%"
                    android:repeatCount="1"
                    android:repeatMode="restart"
                    android:toDegrees="360" />

            </set>

        </set>

</set>




Screenshots:





Source code:

Click to download
